GB50517-2010石油化工金属管道工程施工质量验收规范(英文版)

作者：住房和城乡建设部

ISBN：9787518202775

出版时间：2015年11月

出版社：中国计划出版社

关键词：石油化工设备

分类：英文版规范

¥400

试读购买

阅读量：0 收藏

简介

本规范共分为12章和2个附录，主要包括：总则，术语，基本规定，管道分级，管道材料验收，管道预制，管道焊接，管道安装，管道焊接检查和检验，管道试验，管道吹扫，交工技术文件。本规范适用于设计压力不大于42MPa,设计温度不低于-196℃的石油化工金属管道工程的施工质量验收。

封面
书名页
版权页
Foreword
目录
1　General Provisions
2　Terms
3　Basic Requirements
4　Piping Class
5　Examination and Acceptance for Piping Materials
- 5.1　General Requirements
- 5.2　Examination and Acceptance for Pipes
- 5.3　Examination and Acceptance for Valves
- 5.4　Examination and Acceptance for Other Piping Components
- 5.5　Examination and Acceptance for piping Supports and Hangers
6　Piping Fabrication
- 6.1　Pipe Fabrication
- 6.2　Bend Fabrication
- 6.3　Jacketed Piping Fabrication
- 6.4　Spool Fabrication
7　Piping Welding
- 7.1　General Requirements
- 7.2　Grooving and Joint Assembly
- 7.3　Welding
- 7.4　Preheating and Heat Treatment
8　Piping Installation
- 8.1　General Requirements
- 8.2　Installation of Piping Connected to Rotating Machine
- 8.3　Installation of Non-ferrous Metal Piping
- 8.4　Installation of Tracers
- 8.5　Installation of Lined Piping
- 8.6　Installation of Safety Devices
- 8.7　Installation of Compensating Devices
- 8.8　Installation of Supports and Hangers
- 8.9　Installation of Electrostatic Grounding System
9　Examination and Acceptance for Piping Welds
- 9.1　General Requirements
- 9.2　Visual Examination of Welds
- 9.3　NDE of Welded Joints
- 9.4　Hardness Test
- 9.5　Examination of Ferrite Content in Welds
10　Piping Test
- 10.1　General Requirements
- 10.2　System Set-up
- 10.3　Hydrostatic Test
- 10.4　Pneumatic Test
- 10.5　Initial Service Leak Test
- 10.6　Leak Test and Vacuum Test
11　Piping Cleaning
- 11.1　General Requirements
- 11.2　Cleaning System Set-up
- 11.3　Air Purging
- 11.4　Steam Blowing
- 11.5　System washing
- 11.6　Chemical Cleaning
- 11.7　Piping Degreasing
- 11.8　Oil Washing
12　Technical Documents of Construction Completion
Appendix A　Common Toxic and Combustible Substances
Appendix B　Piping Classification Code
Explanation of Wording in This Code
List of Quoted Standards
